gbs 8100 descriptions
● 5V IN (P1, P2) Power input: Choose one of the two interfaces, “+” is connected to +5V DC power input, and the ground wire corresponds to “-” pole.
● VGA IN (P3) VGA input: Connect to VGA source (such as HD game VGA port, or computer VGA port。
● VGA OUT (P4) VGA output: Connect to a VGA display device, such as a liquid crystal display.
● VIDEO OUT (P5) Video output: Connect to a TV or other video display device.
● S-VIDEO OUT (P6) S-Video Output: Connect to a TV or other video display device.
● RGBS (CGA) OUT CGA signal output: Connect to the scan board.
gbs 8100 Parameter
1. Model Number: gbs 8100
2. Input signal format support: 640x480@60/72/75/85Hz,
800x600@60/75Hz, 1024x768@60/75Hz, 1280x1024@60Hz.
3. Output RGBS format support: 15KHz horizontal frequency signal.
4. Output standard video: CVBS, S terminal.
5. Technical characteristics: English OSD Adjust menu; Video/S-Video output
6. 24 professional video processing chip, output a variety of video signals.
7. The color reproduction is good, the image has no dry spots and no jaggedness.
8. Plug and play, easy to operate.
9. A variety of system switching, adapt to a variety of display
tubes and national television sets.
A: Our Payment terms are TT, Western Union, LC, B/L against copy, etc.
A: Yes, we supply OEM/ODM/OBM service.
A: Yes, we can provide samples within 2 days.
A: Our sample time is around 2 days, formal order lead time is 10 days if urgently 7 days.
A: 1,000pcs per Day.
A: Our quality warranty is 1 year.
A: Normal export packaging.
A: We are a factory specializing in this field for more than 10 years.
